The UL AWM 2468 flat ribbon cable is designed for high-performance internal wiring applications where flexibility, safety, and precise signal transmission are essential. Featuring PVC gray insulation with red or blue stripe marking, this cable supports a rated voltage of 300V and operates reliably at temperatures up to 80ºC.
Manufactured with tinned or bare copper conductors, available in both stranded and solid construction, it provides excellent electrical conductivity and stable connectivity. The cable is offered in multiple pitch distances (1.50mm, 2.00mm, 2.10mm, or customizable options) to support various connector types and assembly requirements. Its uniform insulation thickness ensures easy stripping and processing during installation.
Compliant with UL758, UL1581, and C22.2 No.210 standards, this ribbon cable passes the UL VW-1 and CSA FT1 vertical flame tests, delivering enhanced flame resistance for safer operation.
Ideal for:
Internal wiring of electronic and electrical equipment, computer systems, IDC connectors, mainframes, speakers, lighting equipment, wiring harnesses, and a wide range of electronic devices and appliances.
