Algemene specificatie
| Detail | Parameter | Remarks | ||
| Display mode | Chinese LCD single chip microcomputer | |||
| Model | RS-01 | |||
| Capacity | 100mm length, 2500 pieces per hour | Customized non-standard models, subject to actual production capacity | ||
| Applicable wire diameter | AWG14#-AWG26# | |||
| Processing length | Adhesive gap: 80mm-600mm | |||
| Length of skinning | Ideal range: 0.1mm to 12mm | |||
| Cut-off error | Correctable | |||
| Pressing capacity | 2.0 Ton | |||
| Monitoring unit | Knot detection, end detection, missing thread detection | |||
| Auxiliaries | Waste Paper Reel Device Material Strip Shear | |||
| Source | AC220 single-phase 8A | |||
| Gewicht | Approximately 350kg | |||
| Size | 1560mm long * 720mm wide * 1550mm high | No protrusions | ||
Overzicht
| Naam | Brand | Unit | Number of packages | Place of production |
| Tool holder precision screw | TBI | Cover | 1 | Taiwan |
| Tool holder slide rail | Silver | Cover | 1 | Japan |
| Translation Slide | Shangyin | Cover | 4 | Taiwan |
| Air cylinder | Yadke | Individual | 10 | Taiwan |
| Electromagnetic valve | Yadke | Bit | 14 | Taiwan |
| Filter | Yadke | Cover | 1 | Taiwan |
| Air contactor | Intellectual circles | Individual | 1 | Taiwan |
| Electric relay | OMRON | Individual | 3 | Taiwan |
| Air tube | Taurus Head | Taiwan | ||
| Gas pope joint | Yadke | Taiwan | ||
| Bearing | NSK | Japan | ||
| Key | Izumi | Individual | 3 | Japan |
| Fibre amplifier | Jiazhun | Individual | 2 | Taiwan |
| Display screen | Step foot | Individual | 1 | Shanghai |
| Closed loop motor | R&D Control | Individual | 1 | Shenzhen |
| Closed loop drive | R&D Control | Individual | 1 | Shenzhen |
| Step drive | Servo electronics | Individual | 9 | Shenzhen |
| Stepper motor | Shen Li | Individual | 9 | Shenzhen |
| Servo motor | HuiChuan | Individual | 2 | Shenzhen |
| Servo drive | HuiChuan | Individual | 2 | Shenzhen |
| Stress management | Solu | Japan (optional) |
